Summit 24" Wide Built-In Beer Dispenser, ADA Compliant SBC56GBIADA
32 inch height allows installation under lower counters following ADA guidelines
In Stock & Ready to Ship. Buy with confidence.
All orders are shipped within 1-2 business days. Product ETA 5-7 business days. See our Price Match Guarantee Policy.
Features
Sized at 32 inches high (32.25 to hinge cap) for installation under lower ADA compliant counters
ETL-S listed to NSF-7 commercial standards and meets UL-471 for use in foodservice settings
Front-breathing design allows fully recessed installation under counters
Includes a 5 lb. CO2 tank and regulator, dual tap draft arm, Sankey American tap, and connection hardware
Twin draft tower allows you to serve from two 1/6 (sixtel) sized kegs
Heat resistant design provides clear view to promote impulse buys
Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Interior dial thermostat ensures easy temperature management
No-frost operation for minimum user maintenance
User-reversible door swing allows you to easily adjust to better accommodate your setting
Removable two-piece drip tray included for added convenience
Durable railing makes it easier to neaten service
Turn the light on when you need it and off when you're done with a convenient rocker switch
Bracket is installed inside, allowing you to save on depth by keeping the tank behind your kegs
Interior includes steel cover to protect the floor when loading kegs
Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Cold wall design with hidden evaporator and seamless interior
Allows the unit to be used freestanding
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Specification
Overview
|
|
---|---|
Height of Cabinet | 32.0" (81 cm) |
Height to Hinge Cap | 32.25" (82 cm) |
Width | 23.38" (59 cm) |
Depth | 23.0" (58 cm) |
Depth with Handle | 24.88" (63 cm) |
Depth with door at 90° | 44.5" (113 cm) |
Capacity | 5.5 cu.ft. (156 L) |
Defrost Type | Automatic |
Door | Glass |
Cabinet | Black |
US Electrical Safety | ETL |
Canadian Electrical Safety | ETL-C |
Sanitation | ETL-S |
Amps | 1.8 |
Voltage/Frequency | 115 V AC/60 Hz |
Weight | 110.0 lbs. (50 kg) |
Parts & Labor Warranty | 1 Year |
Compressor Warranty | 5 Years |
UPC | 761101062846 |
Kegerator
|
|
Door Swing | RHD |
Reversible | Yes |
Tap Kit | Yes |
Height with Tap | 47.5" (121 cm) |
Number of Taps | 2 |
Thermostat Type | Dial |
Interior Light | Yes |
Fan Type | Exterior |
Refrigerant | R600a |
Refrigerant Amount | 0.67 oz. |
High Side PSI | 124.0 |
Low Side PSI | 30.0 |
Inter Height | 26.0" (66 cm) |
Interior Width | 21.0" (53 cm) |
Interior Depth | 18.0" (46 cm) |
Compressor Step Height | 7.0" (18 cm) |
Compressor Step Width | 21.0" (53 cm) |
Compressor Step Depth | 5.5" (14 cm) |
Temperature Range | 34º to 43ºF |
