Summit 62 lb. Clear Outdoor/Indoor Icemaker BIM68OSGDR

Summit's commercially listed BIM68OS series icemakers are an attractive and durable solution to keeping a continuous supply of clear ice on hand in virtually any indoor or outdoor location. Sized at 15" wide, the BIM68OSGDR features a complete 304 grade stainless steel exterior specially built to hold up to the elements. The user-reversible door is designed with a powerful magnetic gasket to ensure proper insulation, with a stainless steel handle mounted horizontally for a modern look. The front-breathing design allows built-in installation under counters, while the fully finished stainless steel cabinet also allows freestanding use, with a sealed back for added outdoor protection and easier cleanup. This model utilizes a gravity drain system. The BIM68OSGDR produces clear gourmet dice-style ice cubes, perfect for keeping any beverage cold without diluting the flavor. Under standard operating conditions, this unit can make up to 62 lbs. in a day cycle, while the storage bin can hold up to 26 lbs at a time. We include an ice scoop that can be hung inside for easy use. Frost-free operation eliminates the need to defrost the interior. Designed and manufactured for us in South Korea, the BIM68OSGDR is ETL-S listed to NSF-12 commercial standards for use in foodservice settings. The weatherproof constructed allows outdoor use, but this model can also be installed indoors in any kitchen or wet bar. A panel-ready version (BIM68OSGDRIF) will be available later this year. NOTE: This unit requires professional installation. Drain hose and other connection equipment is not included.

Overview
Height of Cabinet	33.5" (85 cm)
Height to Hinge Cap	33.63" (85 cm)
Width	14.88" (38 cm)
Depth	22.63" (57 cm)
Depth with Handle	24.5" (62 cm)
Depth with door at 90°	37.25" (95 cm)
Capacity	0.98 cu.ft. (28 L)
Defrost Type	Frost-Free
Door	Stainless Steel
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	4.0
Voltage/Frequency	115 V AC/60 Hz
Weight	105.0 lbs. (48 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101057088
Icemaker
Door Swing	RHD
Reversible	Yes
Daily Ice Production	62.0 lbs. (28 kg)
Ice Storage Capacity	26.0 lbs. (12 kg)
Ice Shape	Dice
Size of Cube	1 1/4" H x 1 1/8" W x 1 1/8" D
Number of Ice Cube Sizes	1
Fan Type	Exterior
Refrigerant Type	R134a
Refrigerant Amount	7.4 oz.
High Side PSI	210.0
Low Side PSI	105.0
Interior Height	12.75" (32 cm)
Interior Width	12.75" (32 cm)
Interior Depth	9.25" (23 cm)
Level Legs	4
